Battery |
2X75AH | 2X100AH |
| Motor power |
24V 1500W |
|
| Charger |
24V 8A |
24V 10A |
| Front Tire |
15*6.00-6 |
|
| Rear Tire |
15*6.00-6 |
|
| Max. climbing degree |
15° |
|
| Max. speed (km/h) |
15km/h |
|
| Max. loading weight |
300 kgs |
|
| Travel Range |
50km |
60km |
| Overall dimensions |
1690×1000×1110mm |
|
| Total Weight w/Bat. |
220kg |
|
| Turning Radius |
1.6m |
|
| Ground Clearance |
155mm |
|
| Drive System |
24V Sealed Mid Transaxle |
|
| Brake System |
electromagnetic brake |
|
| Wheel Hub |
Aluminum Alloy |
|
| Seating |
Extr wide double seat and Position Adjustment |
|
| Qty/20' |
22pcs |
|
| Qty/40'HQ |
63pcs |
|
