Battery |
2X55AH | 2X75AH |
| Motor power |
24 800W |
|
| Charger |
24V 5A |
24V 6A |
| Front Tire |
4.10/3.5-6 |
|
| Rear Tire |
4.10/3.5-6 |
|
| Max. climbing degree |
15° |
|
| Max. speed (km/h) |
14km/h |
|
| Max. loading weight |
140 kgs |
|
| Travel Range |
40km |
50km |
| Overall dimensions |
1380×660×1195mm |
|
| Total Weight w/Bat. |
115kg |
131kg |
| Turning Radius |
1.35m |
|
| Ground Clearance |
100mm |
|
| Drive System |
24V Sealed Mid Transaxle |
|
| Brake System |
electromagnetic brake |
|
| Wheel Hub |
Aluminum Alloy |
|
| Seating |
360° Swivel and Position Adjustment - Foldable seat w/ arm rest and head rest |
|
| Qty/20' |
36pcs |
|
| Qty/40'HQ |
72pcs |
|
